Other high-performance epoxy boards
Feature:
1. Flame retardant grade is UL94-V0
2. Excellent heat resistance, glass transition temperature Tg130 ℃
3. Produce yellow, water green, natural color, titanium white, black, etc
Application:
1. New energy epoxy plate heating film
2. New energy battery spacer
Category:
Other high-performance epoxy boards
Download:
Keyword:
New energy epoxy plate heating film
New energy battery spacer
Product Details
| Number | Test Item | Test Condition | Unit | Test Method | Specification IPC-4101E/21 |
Typical Value |
| 1 | Glass Transition (Tg) | E-2/105 | ℃ | IPC-TM-650 2.4.25 | -- | 135 |
| 2 | CTE/ Z-Axis Expansion | 50-260 | % | IPC-TM-650 2.4.24 | -- | 4.5 |
| 3 | Thermal cracking temperature Td | 5%失重 | ℃ | IPC-TM-650 2.4.24.6 | >305℃ | 315 |
| 4 | Moisture Absorption | D24/23 | % | IPC-TM-650 2.6.2.1 | ≤0.05 | 0.40 |
| 5 | Thermal conductivity | 80C | W/mk | ASTM D5470 | -- | 0.45 |
| 6 | Flame retardancy | E-23/24 | Rating | UL94 | UL94-V0 | pass |
| 7 | Density | / | g/cm³ | ASTM D-792 | -- | 1.95 |
| 8 | Dielectric Breakdown | 2.5.6 | KV | IPC-TM-650 2.5.6 | ≥40 | 55 |
| 9 | Comparative Tracking Index | / | V | IPC-TM-650 2.4.8 | -- | 175 |
